Full Auto High Speed Optical Subway Turnstile Barrier Gate Bi - directional

Place of Origin : Shenzhen, China
Brand Name : WEJOIN
Certification : SO 9001:2008, CE,
Model Number : WJTS112S/WJTS122S/WJTS110S/WJTS111S
MOQ : 1set
Price : negotiation
Packaging Details : Export Wooden Case
Delivery Time : 3-15 days depending on the quantity
Payment Terms : T/T, Western Union
Supply Ability : 1, 000 set/month
Trade Terms : Ex works, CIF
Driving Force : 3KG
Frequency : 50/60HZ
Rotating Direction : Double Direction
Rated Power : 36W
Transit Speed : 30~40 persons/min
Length of Pole : 490mm
Contact Now

High Speed Optical Subway Turnstile Barrier Gate Bi - directional


Quick Detail:


Name: Semi-automatic Tripod turnstile

Driving Motor: Brushless DC Motor

Rotating Direction: Double Direction

Transit Speed: 30~40 persons/min

Rated Power: 36W

Power Supply: 220V±10%, 110V±10%



Function and Features:


﹤1﹥. Self-locking within 5 seconds if there is no one passing after signal activation

﹤2﹥. Passable for bi-direction

﹤3﹥. A compact electro-mechanical design with an exquisite rotating plate and a self-lock mechanism

﹤4﹥.Arm auto dropping when power off and manually put the arm up when power on

﹤5﹥. Person counter output is available to indicating passenger quantity; the pulse is 200MS

﹤6﹥. Emergency Alarm interfaces available for alarm equipments under 12W or DC12V

﹤7﹥. Fire alarm emergency signal output: if with arm auto drop function, the arm will drop automatically after signal activation; if not, the arm rotating plate can operate freely and there is alarm after signal activation

﹤8﹥. Input interfaces available for left access(L), right access(R), emergency(EM), GND; EM is in priority; NO electrical replay output with pulse between 200MS~500MS; EM signal should maintain connected when any emergency happens.

﹤9﹥. Output interfaces available for passenger counters (left and right side); it is dynatron OC output with the pulse of 200MS; working with devices of DC 5V, 12V, 24V.

﹤10﹥.Able to avoid unauthorized access


Specifications:


Model
Item
WJTS122SWJTS110SWJTS112SWJTS111S
Manual, Semi or Full-automaticSemi-automatic
Material of Housing304 Stainless SteelIron with Powder
Thickness of Housing1.50mm
Dimension of Housing
(L×W×H mm)
420×380×10001235×280×10001235×280×1000420×380×1050
Length of Pole (out of housing)490mm
Net Weight40kg70kg70kg35kg
Max Load-bearing of Pole80kg
Driving Force of Pole3KG
Rotating DirectionDouble Direction
Power Supply220V±10%, 110V±10%
Frequency50/60HZ
Working Voltage of MotorDC12V
Rated Power36W
Driving MotorBrushless DC Motor
Input Interfacedry contact with the pulse between 200ms~500ms
Transit Speed30~40 persons/min
Working Temperature-40°C~55°C
Working EnvironmentIndoor / Outdoor (Shelter)
Relative Humidity≤95%

Applications:


The tripod turnstiles can be used in places such as restaurants, hotels, office buildings, museums, gyms, clubs, metros, bus stations, high class communities, intelligent buildings, hotels, subway stations and other high level venues, ect.


After-sale Service:


1 year warranty

Lifetime Service with charge accordingly
